Screw-drivable anchor with 3-axis accelerometer and temperature sensor

Applications

• Scanner / Repeater
• Asset tracking
• Presence detection
• Temperature measurement
• Movement detection
• Free-fall alert

Available Firmware

• Presence detection (Bluetooth® LE)
• Proximity positioning (EchoTag®)
• Accurate positioning (Quuppa® Emulation Pro)

Data packets

• iBeacon (Apple iBeacon™ standard)
• Eddystone-UID (Unique identifier)
• Eddystone-URL (Physical Web)
• Eddystone-TLM (Telemetry with temperature and battery voltage)
• ALT-Beacon (Open and Interoperable specification)
• Secure Beacon (BLINQY secure frame format with AES-128 symmetric encryption)
• Proprietary (Custom frame)

Options

• Visible LEDs
• NFC (13.56 MHz, read only)
• Laser engraving
• Silkscreen Printing

Sensors and Actuators

• Accelerometer User-selectable full scales of ±2g/±4g/±8g/±16g and is capable of measuring accelerations with
  configurable trigger events:
  • Single tap
  • Double tap
  • Wake-up movement
  • Flip-flop
  • Free-fall
• Temperature sensor allowing an accuracy
  • from 0°C to 70°C: ± 0.8°C (1)
  • from -40°C to +85°C: ± 1.3°C (1)
• LEDs red and green

Battery

• Reference AA
• Quantity 2 units
• Capacity 2450 mAh @21°C @25mA continuous discharge to 0.8 volts
• Voltage 2 x 1.5 Volts

Environmental properties

• Protection IP68
• Splashproof Yes (1m, 24h)
• Dustproof Yes

Chemical properties

• Resistance Saltwater, salt mist, acetic acid water, carbonated sodium water, sugared water, ethylene glycol
• Humidity 95% (50°C, 24h)

(1) Typical specifications are not guaranteed
